Online EU Version 0475 Fgtech Galletto 4 Master V54 Support BDM-Tricore-Boot-OBD FG TECH FW 0475 Car Truck ECU Programmer

XTY14615
1.2KG
Price:
USD
$69.99
$80.00
    Please select the information you wantX
  • Ships From:
    China
    Germany
    Russia
Quantity:
-
+
(600 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews(1)


Warm Tips:


1. When you install 0475, you can keep online, but please close all anti-virus software.

2. This Fgtech is newest firmware 0475, the software version is 2012/02 version, which is not same as old fgtech 0386. So our new 0475 cannot work on old fgtech....

3. If your CD is broken, you can contact us for software download link.



Difference Between FGTECH FW 0475 And FW 0386:

1. FW 0475 EU Version fixed all unstable problem and errors which FW 0386 had. MCU, EEPROM , Relay, Resistance, Led, Solder , Pin, Capacitor these all are corrected

2. FW 0475 EU Version Adds new components, best usb bridge and relays. Work well with OBD / BDM / Boot / Tricore, However FW 0386  is not good at Tricore.

3. FW 0475 EU Version Adds much more and newer vehicles and ECU protocols than FW 0386.

4. FW 0475 EU Version Support more OS : Win7 32bit and 64bit / Vista, However FW 0386 can only work well with win xp.

5. FW 0475 EU Version is unlocked version ,support online operation, means you can connect internet during use, However FW 0378 must disconnect internet during use.

6. FW 0475 EU Version software version is same version V2012.02 as FW 0386 , But actually the software and driver is different. 0475 version software is more user-friendly.



Description:

FGTech Galletto 4-Master this new system developed with high-speed USB2 technology is the fastest and most secure product on the market, it is easy to install and use by anyone. Our system comes furnished complete with all Car, Truck, Motorbike, Marine, BDM MPICxx, BDM Boot Mode Tricore, checksum..

FG Tech Galletto 4-Master V54 BDM-OBD is a famous chip tuning tool for all cars, trucks, motorcycles, Marine, BDM MPCxx, BDM Boot Mode, checksum. This item cannot only work as FGTech Galletto 4-Master, but can also work for BDM-TriCore-OBD.

Fgtech V54 supports Multi-languages:  English, Spanish, French, Italian, German, Czech, Portuguese, Turkish

fGTECH 0475 language




FGTECH 0475 Added New Car Models Than Old 0386 Version:

11/12
OBD driver for SSangyong Del-phy DCM3.7 Read/Write, Checksum
11/12
OBD driver for Ferrari 458 Italia MED9.6 Ecu Master and ECU Slave Read/Write, Checksum
10/12
OBD driver for Fiat/for Alfa/for Lancia Twinair/for Multiair 8GMF and 8GSF Read/Write, Checksum
10/12
OBD driver for MD 5, MD 6 2.0 Diesel ECU RF8x Read/Write, Checksum
10/12
OBD driver for MD 5, MD 6 2.0 Diesel ECU RF7x Read/Write, Checksum
09/12
OBD driver for Sim-os 10.xx for VAG 1.2 TSI Read/Write, Checksum
09/12
OBD driver for CRD 3.xx BZ 2200 CDI Read/Write, Checksum
09/12
Simos PCR2.1 VA-G 1.6 TDI Unlock Boot Tool - Read/Write EEPROM
09/12
OBD driver Sim-os PCR2.1 forVAG 1.6 TDI Read/Write, Checksum
07/12
OBD driver Del-phi DCM3.5 for Tata Sa-fari  Read/Write, Checksum
07/12
Checksum recognition for DCM3.7 for Ssangyong
07/12
Checksum recognition for DCM3.7 for Opel and for Saab
07/12
Checksum recognition for DCM3.7 forKia  and forHyundai
07/12
Boot Visteon ST10F275 RX-TX Mode
07/12
Boot ME7.9.10 ST10F275 RX-TX Mode
06/12
Checksum recognition for Denso for Sub Tri-beca
06/12
Boot for Mitsubishi MH7203 forHyundai
06/12
Checksum recognition for Denso NS L200
06/12
Checksum recognition for Denso NS X-Trail
06/12
OBD driver for Opel Simtec75 CAN  Read/Write, Checksum
05/12
OBD driver for Pors-che SDI3 CAN  Read/Write, Checksum
05/12
for Corvette Utility CAN for change VIN, Code Align, Erase Errors
05/12
for Corette Utility VPN for change VIN, Code Align, Erase Errors
05/12
OBD driver RT SID305 CAN  Read/Write, Checksum
05/12
OBD driver for Masrati ME9 CAN  Read/Write, Checksum
04/12
Tool Boot for Hitaci Phase 3
04/12
Tool Boot for Hitaci Phase 2
04/12
OBD driver forFiat ME17.31 CAN  Read/Write, Checksum
04/12
Boot forMitsubishi for L200 MH8102F
03/12
Boot forMitsubishi for Lancer EVO MH7202
03/12
forFiat MJ8DF CAN Serial Injectors
03/12
forFiat MJ8DF CAN Serial Injectors
02/12
OBD driver forFiat MJ8DF CAN Read/Write, Checksum
02/12
OBD driver forFiat MJ8DF K-line Read/Write, Checksum
02/12
OBD driver BZ Del-phi CRD2.xx CAN Read/Write, Checksum
01/12
OBD driver FD Del-phi DCM3.5 CAN Read/Write, Checksum
01/12
OBD driver PSA Delp-hi DCM3.5 CAN  Read/Write, Checksum
01/12
OBD driver forVAG Sim-os 3xx Boot mode 29F400 C167 Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 9.1 Boot mode 29F400 C167 Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 7.1 Boot mode 29F400 C167 Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 33 K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 32 K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 3PG K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 3PE K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 3PD K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 3PC K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 3PA K-line serial Read/Write, Checksum
12/11
OBD driver forVAG Sim-os 9.1 K-line Read/Write, Checksum
11/11
JTAG MPC55xx
10/11
New password Triore Tprot V08-10
10/11
OBD driver RT Val-eo V40, Read/Write, Checksum
10/11
AUD Ren-esas
10/11
Boot Ren-esas
...


NEW forVAG SIMOS PCR2.1
NEW JTAG - BDM - for- FREESCALE -
NEW JTAG RENESAS
Freescale MPC 5553/5554/5565/5566 NEXSUS PORT New IAW MJD 8F2
Mair 8GMF New Delphy DCM3.5xx DCM3.7xx TRW.
Motorola Freescale MPC 555/556/561/562/563/564/565
Motorola MC 68332 - MC YQQCU - MC 68377 Trionic 5/7/8 for G..M-forOPEL-forSAAB
Motorola MC 68376 Campi 01 Lambor-ghini - for Lotus
Motorola MC 68336 MEMS D5 for ROVER
Motorola ZC 439615 - ZC 439507 IAW forFIAT - forVAG
New Line OBD protocols VPM for GM for Hummer-Corvette-for Munstang-for Blazer-for Cadilac
New Line OBD protocols Tx - Rx Sub - for Mitsubischi - for Hit-achi - Den-so ecu
NEW JTAG - BDM - MOT - FREESCALE :
Freescale MPC 5553/5554/5565/5566 NEXSUS PORT New IAW MJD 8F2 - Mair 8GMF
New Delphy DCM3.5xx DCM3.7xx TRW
MOT Free scale MPC 555/556/561/562/563/564/565
MOT MC 68332 - MC YQQCU - MC 68377 Trionic 5/7/8 G-for OPEL-for SAAB
MOT MC 68376 Campi 01 for Lamb-ogini - for Lotus
MOT MC 68336 MEMS D5
MOT ZC 439615 - ZC 439507 IAW FIT - for V A G
New Line OBD protocols VPM  for Humer-for Corvette-for Munstang-for Blazer-for Cadilac
New Line OBD protocols Tx-Rx - Sbr - for Mitsubischi - for Hitachi - Denso ecu
All EDC17 MED17 is good always modify with Boot Mode .



Master Version:

1.Recovery Mode Completa
2.Funzione scan tool per eliminare i DTC
3.Function scan tool for erase the DTC
4.Controllo tensione di batteria auto in tempo reale
5.Check tension of battery car in real time



Automatic Checksum:

All old protocols included from forbosch MExx/EDCxx/Marelli/Siem-ens/Delpy/Lucas/Denso Boot Mode C167x/ST10, Boot Mode Infin--eon Tric--ore With password forbosch, Siem-ens For Moto-rola MC68332 - MCYQQCU - MC68377, MC68376, MC68336, ZC439615, ZC439507 For Motor-ola Frees-cale MPC 555/556/561/562/563/564/565 Freescale MPC 5553/5554/5565/5566 BDM Tricore.
5-30V Car/Industrial Vehicles, L line/K line KWP, CAN
Can Bus V2.0 50Kb > 1000Kb
Rx Tx RS232,
RS 485,
Automatic setup Pull up K-L line 250, 500, 1000 ohm,
Automatic setup termination Can bus 0, 60,120 ohm,



Connections:

BDM Connection:


Boot Connection:

OBD2 Cable Connection:



Package list:

1* FGTECH Galletto 4-Master V54 Main Unit
1* ECU cable for boot
1* Adapter for BDM to CMD with BDM cables
3* BDM adapters
6* BDM connectors
2* Power cable
1* OBD2 cable
1* USB cable (1.5meter)
1* CD
